Name: 5kv Airport Airfield MV Power Cable Copper Conductor PVC jacket
Brand: CN CABLE
Price: 1 USD

Brand Name : CN CABLE

Model Number : MV CABLE

Certification : IEC

Place of Origin : Henan

MOQ : 1000meters

Payment Terms : L/C, T/T

Delivery Time : 20 days

Packaging Details : wooden drum. iron-wooden drum

Name : MV Power Cable

Conductor : Copper

Insulation : XLPE Insulation

Screen : Copper Tape

Sheath : PE

Color : Purple or Black

Contact Now

5kv Airport Airfield MV Power Cable Copper Conductor PVC Jacket

MV Power Cable construction:

A. Bare or Stranded Tinned Cu Conductor

B. Semi-conductive Layer

C. XLPE insulation

D. Semi-conductive Layer

E. Copper tape shielding

F. PVC jacket

Packing Material:Coil, Box, Pallet, Drum

5kv Airport Airfield MV Power Cable Copper Conductor PVC jacket

MV Power Cable Parameters

Section Area Nominal (mm2)	Insulation thickness nominal (mm)	Shielding	Copper Tape Thickness (mm)	Outer sheath	Outer Diameter Approx. (mm)	Weight (kg/km)
1 x 6	2.2	Copper Tape	0.10	XLPE	13.8	263
1 x 6	2.2	Copper Tape	0.10	PVC	13.8	278
1 x 6	2.2	Copper Tape	0.10	PE	13.8	263
1 x 8 AWG	2.2	Copper Tape	0.10	XLPE	14.2	285
1 x 8 AWG	2.2	Copper Tape	0.10	PVC	14.2	315
1 x 8 AWG	2.2	Copper Tape	0.10	PE	14.2	285
